BOOST YOUR ADVENTURE
Portable, Home, and Commercial Electric Vehicle Charging Solutions
EXPRESS YOUR CHARGING NEEDS
SPECIFICATIONS*
LEVEL 1 120V AC Home Charger
12, 16 amp Configuration | 1.44, 1.92 kW Configuration Power | -40°F to 140°F Operating Temperature | NEMA 5-20 3ft Input Cable and Connector | SAE J1772 25ft Output Cable and Connector | LED Light Indicators | IP66 Weather Proof and Dust Proof | IK10 Impact Resistance | Integrated Cable Management | Built-In WiFi Connectivity 802.11 b/g/n 2.4 GHz | UL and cUL Listed | NEC 625, Energy Star Certified | FCC Part 15 Class B | Open ADR 2.0b Compliant
LEVEL 2 240V AC Home Charger
Single Phase 240 V ac | 16, 24, 32, 40 amp Configuration | 3.8, 5.7, 7.6, 9.6 kW Configuration Power | 40°F to 140°F Operating Temperature | NEMA 14-50 3ft Hardwired Input Cable and Connector | SAE J1772 25ft Output Cable and Connector | LED Light Indicators | IP66 Weather Proof and Dust Proof | IK10 Impact Resistance | Integrated Cable Management | Built-In WiFi Connectivity 802.11 b/g/n 2.4 GHz | UL and cUL Listed | NEC 625, Energy Star Certified | FCC Part 15 Class B | Open ADR 2.0b Compliant | SAE J1772, J2847, 2894, UL 1998, 2202, 2251, 2594
LEVEL 3 DC Fast Charger
50kW Power | 50 to 500V DC Output Voltage | <100W Idle Power Consumption | -35°F to 113°F Operating Temperature | >90% Efficiency | .99 Power Factor | CHAdeMO and CCS Output Cable and Connector | IP66 Weatherproof and Dust Proof | IK10 Impact Resistance | MEMA Type 3R | 4G and Gigabit Ethernet | Open ADR 2.0 | UL, cUL, CHAdeMO, CALeVIP
* Specifications are projected estimations and requirements subject to change.
